78W Flat Clay Customisable Power Generating Solar Tiles
78w grey flat panels will generate electricity moving tiles. Turn your roof into a power plant!
- gainsolar
- Information
Advantage
Solar tiles are tiles that generate electricity and have the properties of roof tiles, protecting the roof, keeping it looking low profile and effortlessly reaping the benefits of solar energy towards a cleaner future.
The solar tiles are available in a stylish special grey colour, with the same colour polymer composite resin material as the bottom support, and the accessory tiles and side tiles are also in the same colour and material, so that the roof can maintain a high degree of harmony.
This is a flat tile that can be applied to most roofs. The double-layer toughened glass is designed to withstand extreme weather such as heavy snow and hail, which really protects the roof.
Sgbsolar has also matched the corresponding accessory tiles so that they can be perfectly matched on the roof to achieve a high degree of integrity.
Data sheet
T MAX O PHYSICAL PARAMETERS | |
Product model | JS78DG-13e 1/2 |
Dimensions | 1260*480mm |
Weight | 15.5kg |
Glass (material/thickness) | Tempered glass/3.2mm+3.2mm |
Cell | 182*91mm（2*12） |
Junction box | ≥IP67 |
Cable type | 900mm / 4mm² |
Plug connector | MC4 |
Life span | >30years |
ELECTRICAL PARAMETERS(STC) | |
Solar cells | Monocrystalline |
Power output（Pmax ） | 78W |
Module efficiency（%） | 14.50% |
Voltage at Pmax（V mpp） | 5.63V |
Current at Pmax（I mpp） | 5.68A |
Open-circuit current（Voc） | 6.76V |
Short-circuit current（Isc） | 5.96A |
Power
The 78w T MAX O photovoltaic module uses monocrystalline silicon cells, due to the continuous iteration of technology, monocrystalline silicon has become the most efficient material for power generation on the market, sgbsolar's solar tiles use monocrystalline silicon as the most cellular component, so the T MAX O has to generate power is very efficient, the maximum output power can reach 78w per piece.
As you know, the different colours of PV modules will affect the conversion efficiency, so this grey T MAX O has a maximum output of 78w, and two pieces can be installed on each square metre of roof, generating power of 156w per square metre.
The annual power generation per square metre can reach：
156*4*0.8*365=180kwh
If you install 50 square metres of solar tiles on your roof (the rest of the roof, such as the north-facing roof, is fitted with matching tiles)
The power generation in a year can be up to：
156*4*0.8*365*50=9110kwh
This is a significant amount of power generation, which can effectively reduce the daily electricity bill and protect the roof.
By installing solar tiles, you can keep your roof looking beautiful and at the same time enjoy the benefits of solar energy without much effort, and most importantly, this move is an effort to save energy, reduce carbon emissions and alleviate the harsh environment of the earth.
Contact Us
If you are suffering from high electricity bills and tired of your neighbour's unsightly photovoltaic roof, then why not try solar tiles, which are surely the best choice for you?
Contact sgbsolar for the best roofing solutions!
